保护特性:aR / gR
150-2100V / 1-100A
尺寸:Φ10x38 / Φ14x51 / Φ22x58 / Φ21x127 |
 |
|
■
额定电压150-2100V AC(150V,250V,500V,600V,690V / 700V,750V,1000V,1200V,1400V,2100V)；
■ 用于交流50/60Hz，额定电压150-2100V，额定电流至100A的电气线路中作为半导体器件及其成套装置的短路保护(aR) 和全范围保护(gR)；
■ 符合IEC60269.4标准和GB13539.4标准；
■ 所有圆柱型熔断器采用陶瓷管，双层帽，外帽镀银。 |
|
|
外形尺寸 |
|
 |
|
型号 |
A |
B |
|
BS10 |
10 |
38 |
|
BS14 |
14 |
51 |
|
BS22 |
22 |
58 |
|
BS21 |
21 |
127 |
|
|
|
技术参数 |
|
|
|
 |
|
|
| ■ 150V AC/DC |
|
Φ10x38 |
额定电流
(A) |
功耗
(W) |
弧前
I2t(A2s) |
熔断
I2t(A2s) |
订货型号 |
|
150V AC/DC
aR
100kA
@ 150V AC
50kA
@ 150V DC |
5 |
1 |
1.6 |
8 |
BS10-5A/150V AC aR |
|
10 |
2.7 |
3.6 |
16 |
BS10-10A/150V AC aR |
|
15 |
3.3 |
14 |
55 |
BS10-15A/150V AC aR |
|
20 |
3.8 |
33 |
130 |
BS10-20A/150V AC aR |
|
25 |
4.9 |
58 |
220 |
BS10-25A/150V AC aR |
|
30 |
4.9 |
100 |
400 |
BS10-30A/150V AC aR |
|
|
|
| ■ 250V AC/DC |
|
Φ14x51 |
额定电流
(A) |
功耗
(W) |
弧前
I2t(A2s) |
熔断
I2t(A2s) |
订货型号 |
|
250V AC/DC
aR
100kA
@ 250V AC
50kA
@ 250V DC |
1 |
-- |
-- |
-- |
BS14-1A/250V AC aR |
|
2 |
-- |
-- |
-- |
BS14-2A/250V AC aR |
|
3 |
-- |
-- |
-- |
BS14-3A/250V AC aR |
|
4 |
-- |
-- |
-- |
BS14-4A/250V AC aR |
|
5 |
1.3 |
1.6 |
13 |
BS14-5A/250V AC aR |
|
10 |
3.4 |
3.6 |
24 |
BS14-10A/250V AC aR |
|
15 |
3.8 |
14 |
83 |
BS14-15A/250V AC aR |
|
20 |
4.6 |
33 |
200 |
BS14-20A/250V AC aR |
|
25 |
5.3 |
58 |
300 |
BS14-25A/250V AC aR |
|
30 |
5.9 |
100 |
500 |
BS14-30A/250V AC aR |
|
50 |
7.5 |
200 |
1800 |
BS14-50A/250V AC aR |
|
|
|
 |
 |
|
|
| ■ 500V AC/DC |
|
Φ14x51 |
额定电流
(A) |
功耗
(W) |
弧前
I2t(A2s) |
熔断
I2t(A2s) |
订货型号 |
|
500V AC/DC
aR
100kA
@ 500V AC
50kA
@ 500V DC |
1 |
-- |
-- |
-- |
BS14-1A/500V AC aR |
|
2 |
-- |
-- |
-- |
BS14-2A/500V AC aR |
|
3 |
2.3 |
-- |
-- |
BS14-3A/500V AC aR |
|
4 |
-- |
-- |
-- |
BS14-4A/500V AC aR |
|
5 |
1.5 |
1.6 |
6.4 |
BS14-5A/500V AC aR |
|
6 |
1.5 |
1.6 |
6.4 |
BS14-6A/500V AC aR |
|
10 |
4 |
3.6 |
13 |
BS14-10A/500V AC aR |
|
12 |
-- |
-- |
-- |
BS14-12A/500V AC aR |
|
15 |
5.5 |
10 |
40 |
BS14-15A/500V AC aR |
|
20 |
6 |
26 |
96 |
BS14-20A/500V AC aR |
|
25 |
7 |
49 |
191 |
BS14-25A/500V AC aR |
|
30 |
9 |
58 |
232 |
BS14-30A/500V AC aR |
|
|
|
 |
 |
|
|
| ■ 600V AC/DC |
|
Φ10x38 |
额定电流
(A) |
功耗
(W) |
弧前
I2t(A2s) |
熔断
I2t(A2s) |
订货型号 |
|
600V AC/DC
aR
100kA
@ 600V AC
50kA
@ 600V DC |
6 |
1.5 |
4 |
30 |
BS10-6A/600V AC aR |
|
8 |
2.0 |
6 |
50 |
BS10-8A/600V AC aR |
|
10 |
2.5 |
9 |
70 |
BS10-10A/600V AC aR |
|
12 |
3.0 |
15 |
120 |
BS10-12A/600V AC aR |
|
16 |
3.5 |
25 |
150 |
BS10-16A/600V AC aR |
|
20 |
4.8 |
34 |
260 |
BS10-20A/600V AC aR |
|
25 |
6.0 |
60 |
390 |
BS10-25A/600V AC aR |
|
32 |
7.5 |
95 |
600 |
BS10-32A/600V AC aR |
|
|
|
|
 |
 |
|
|
| ■ 690V/700V AC/DC(IEC/UL) |
|
Φ10x38 |
额定电流
(A) |
功耗
(W) |
弧前
I2t(A2s) |
熔断
I2t(A2s) |
订货型号 |
|
690V/700V AC/DC
aR
100kA
@ 690V AC
50kA
@ 700V DC |
1 |
1.0 |
0.93 |
1.6 |
BS10-1A/690V AC aR |
|
2 |
1.08 |
0.64 |
8 |
BS10-2A/690V AC aR |
|
4 |
1.1 |
0.8 |
10 |
BS10-4A/690V AC aR |
|
5 |
1.5 |
2.0 |
25 |
BS10-5A/690V AC aR |
|
6 |
1.8 |
3.0 |
38 |
BS10-6A/600V AC aR |
|
8 |
1.8 |
3.1 |
39 |
BS10-8A/690V AC aR |
|
10 |
2.3 |
5.1 |
64 |
BS10-10A/690V AC aR |
|
12 |
2.8 |
7.4 |
93 |
BS10-12A/690V AC aR |
|
16 |
3.7 |
13.1 |
164 |
BS10-16A/690V AC aR |
|
20 |
4.7 |
29 |
360 |
BS10-20A/690V AC aR |
|
25 |
5.4 |
52 |
650 |
BS10-25A/690V AC aR |
|
30 |
6.1 |
75 |
980 |
BS10-30A/690V AC aR |
|
32 |
6.4 |
81 |
1010 |
BS10-32A/690V AC aR |
|
|
|
|
 |
 |
|
|
|
Φ14
x51 |
额定电流
(A) |
功耗
(W) |
弧前
I2t(A2s) |
熔断
I2t(A2s) |
订货型号 |
|
690V/700V AC/DC
aR
100kA
@ 690V AC
50kA
@ 700V DC |
1 |
-- |
-- |
-- |
BS14-1A/690V AC aR |
|
2 |
-- |
-- |
-- |
BS14-2A/690V AC aR |
|
3 |
-- |
-- |
-- |
BS14-3A/690V AC aR |
|
4 |
-- |
-- |
-- |
BS14-4A/690V AC aR |
|
5 |
1.5 |
1.6 |
11 |
BS14-5A/690V AC aR |
|
10 |
4 |
3.6 |
38 |
BS14-10A/690V AC aR |
|
15 |
5.5 |
8.6 |
70 |
BS14-15A/690V AC aR |
|
20 |
6 |
26 |
230 |
BS14-20A/690V AC aR |
|
25 |
7 |
46 |
375 |
BS14-25A/690V AC aR |
|
30 |
9 |
58 |
485 |
BS14-30A/690V AC aR |
|
32 |
7.6 |
68 |
600 |
BS14-32A/690V AC aR |
|
40 |
8 |
84 |
750 |
BS14-40A/690V AC aR |
|
50 |
9 |
200 |
1800 |
BS14-50A/690V AC aR |
|
|
|
 |
 |
|
|
|
Φ22
x58 |
额定电流
(A) |
功耗
(W) |
弧前
I2t(A2s) |
熔断
I2t(A2s) |
订货型号 |
|
690V/700V AC/DC
aR
100kA
@ 690V AC
50kA
@ 700V DC |
20 |
5 |
19 |
260 |
BS22-20A/690V AC aR |
|
25 |
6 |
34 |
410 |
BS22-25A/690V AC aR |
|
32 |
8 |
53 |
605 |
BS22-32A/690V AC aR |
|
40 |
9 |
68 |
750 |
BS22-40A/690V AC aR |
|
50 |
10 |
135 |
1600 |
BS22-50A/690V AC aR |
|
63 |
11 |
280 |
3800 |
BS22-63A/690V AC aR |
|
80 |
14 |
600 |
6600 |
BS22-80A/690V AC aR |
|
100 |
16 |
1100 |
12500 |
BS22-100A/690V AC aR |
|
|
|
|
 |
 |
|
|
| ■ 750V AC/DC |
|
Φ21x127 |
额定电流
(A) |
功耗
(W) |
弧前
I2t(A2s) |
熔断
I2t(A2s) |
订货型号 |
|
750V AC/DC
aR
45kA
@ 750V AC
20kA
@ 750V DC |
5 |
-- |
9 |
16 |
BS21-5A/750V AC aR |
|
8 |
-- |
80 |
100 |
BS21-8A/750V AC aR |
|
10 |
-- |
95 |
200 |
BS21-10A/750V AC aR |
|
15 |
-- |
100 |
240 |
BS21-15A/750V AC aR |
|
20 |
-- |
125 |
315 |
BS21-20A/750V AC aR |
|
25 |
-- |
400 |
1100 |
BS21-25A/750V AC aR |
|
30 |
-- |
800 |
2600 |
BS21-30A/750V AC aR |
|
|
|
|
 |
|
|
■ 1000V AC:2-30A
■ 1200V AC:20-30A
■ 1400V AC:8-15A
■ 2100V AC:2-6A |
|
Φ21x127 |
额定电流
(A) |
功耗
(W) |
弧前
I2t(A2s) |
熔断
I2t(A2s) |
订货型号 |
|
1000V AC/DC
gR
45kA
@ 1000V AC
30kA
@ 1000V DC |
2 |
4.5 |
0.8 |
2.5 |
BS21-2A/1000V AC gR |
|
6 |
6.7 |
27 |
80 |
BS21-6A/1000V AC gR |
|
8 |
7.5 |
64 |
192 |
BS21-8A/1000V AC gR |
|
10 |
3.0 |
118 |
277 |
BS21-10A/1000V AC gR |
|
12 |
3.5 |
170 |
380 |
BS21-12A/1000V AC gR |
|
15 |
5.0 |
210 |
500 |
BS21-15A/1000V AC gR |
|
20 |
6.0 |
675 |
1550 |
BS21-20A/1200V AC gR |
|
25 |
6.5 |
1200 |
2760 |
BS21-25A/1200V AC gR |
|
30 |
7.5 |
1850 |
4300 |
BS21-30A/1200V AC gR |
|
|
|
|
 |
|
